ReentrantReadWriteLock
ReentrantReadWriteLock读写锁
定义：假如有一个资源很少去修改它，但是经常去访问它。此时就可以考虑使用读写锁，因为读写锁能保证多个线程同时读，允许同时读-读。但不允许同时写-读、同时写-写操作。
看命名和内部类就知道它同时也能保证公平｜非公平锁，读｜写锁，同时又是可重入锁。
用法：模拟一个场景，1000个循环下，获取一个随机数，是偶数则写数据，是奇数则读数据。
public class RwTest {
public static volatile int salary;
ReadWriteLock rwLock = new ReentrantReadWriteLock();
public static void main(String[] args) {
RwTest rwTest = new RwTest();
for (int i = 0; i < 1000; i++) {
int random = new Random().nextInt();
if ((random & 1) == 0) {
new Thread(() -> {
int salary = 0;
try {
salary = rwTest.getSalary();
} catch (InterruptedException e) {
e.printStackTrace();
}
System.out.println(Thread.currentThread().getName() + " : " + salary + " : " + LocalDateTime.now().format(DateTimeFormatter.ISO_TIME));
}, "Read-" + i + "-" + random).start();
} else {
new Thread(() -> {
int salary = 0;
try {
salary = rwTest.setSalary();
} catch (InterruptedException e) {
e.printStackTrace();
}
System.out.println(Thread.currentThread().getName() + " : " + salary + " : " + LocalDateTime.now().format(DateTimeFormatter.ISO_TIME));
}, "Write-" + i + "-" + random).start();
}
}
}
public int getSalary() throws InterruptedException {
Lock readLock = rwLock.readLock();
readLock.lock();
try {
Thread.sleep(1000);
return salary;
} finally {
readLock.unlock();
}
}
public int setSalary() throws InterruptedException {
Lock writeLock = rwLock.writeLock();
writeLock.lock();
try {
Thread.sleep(1000);
salary += 100;
return salary;
} finally {
writeLock.unlock();
}
}
}
运行结果如下，通过时间可以看出，读锁和写锁之间是互斥的，写锁和写锁之间也是互斥的，但是读锁和读锁之间是共享的。
关于源码的阅读方面，读写锁的实现里有几个需要先了解的概念。
- 原先的AQS中state被拆分为了高16位和低16位，共享锁针对高16位取值，而排他锁针对低16位取值。
- 由于读锁是所有读线程都可以获取的，同时又是可重入的，所以搞了个ThreadLocal存放每个线程获取读锁的个数。
了解完这些概念，再去读源码。读源码肯定是跟着功能接口往下走。
首先针对读锁，加锁的源码如下。
public void lock() {
sync.acquireShared(1);
}
// AQS模版
public final void acquireShared(int arg) {
if (tryAcquireShared(arg) < 0)
doAcquireShared(arg);
}
protected final int tryAcquireShared(int unused) {
Thread current = Thread.currentThread();
// 熟悉的state
int c = getState();
// 如果有写锁并且AOS中排他线程不是当前线程，直接失败返回等待
if (exclusiveCount(c) != 0 &&
getExclusiveOwnerThread() != current)
return -1;
// 如果读锁不用阻塞且读锁小于最大数量且CAS成功 readerShouldBlock在FairSync和NonfairSync中有不同实现
int r = sharedCount(c);
if (!readerShouldBlock() &&
r < MAX_COUNT &&
compareAndSetState(c, c + SHARED_UNIT)) {
// 走到这一步表明CAS成功了，这里就是在存Threadlocal中锁的数量了。
if (r == 0) {
firstReader = current;
firstReaderHoldCount = 1;
} else if (firstReader == current) {
firstReaderHoldCount++;
} else {
HoldCounter rh = cachedHoldCounter;
if (rh == null || rh.tid != getThreadId(current))
cachedHoldCounter = rh = readHolds.get();
else if (rh.count == 0)
readHolds.set(rh);
rh.count++;
}
return 1;
}
// 如果读锁要等待或者CAS失败了
return fullTryAcquireShared(current);
}
final int fullTryAcquireShared(Thread current) {
/*
* This code is in part redundant with that in
* tryAcquireShared but is simpler overall by not
* complicating tryAcquireShared with interactions between
* retries and lazily reading hold counts.
*/
HoldCounter rh = null;
for (;;) {
// 同之前判断写锁并且排他线程
int c = getState();
if (exclusiveCount(c) != 0) {
if (getExclusiveOwnerThread() != current)
return -1;
// else we hold the exclusive lock; blocking here
// would cause deadlock.
// 如果当前线程之前就获取过锁，代表是在重入，此时不为写锁让步，否则看下面
} else if (readerShouldBlock()) {
// Make sure we're not acquiring read lock reentrantly
if (firstReader == current) {
// assert firstReaderHoldCount > 0;
} else {
if (rh == null) {
rh = cachedHoldCounter;
if (rh == null || rh.tid != getThreadId(current)) {
rh = readHolds.get();
if (rh.count == 0)
readHolds.remove();
}
}
// 如果之前没有获取过锁，则不是重入，此时为写锁让步，避免写锁饥饿。
if (rh.count == 0)
return -1;
}
}
if (sharedCount(c) == MAX_COUNT)
throw new Error("Maximum lock count exceeded");
// CAS操作
if (compareAndSetState(c, c + SHARED_UNIT)) {
if (sharedCount(c) == 0) {
firstReader = current;
firstReaderHoldCount = 1;
} else if (firstReader == current) {
firstReaderHoldCount++;
} else {
if (rh == null)
rh = cachedHoldCounter;
if (rh == null || rh.tid != getThreadId(current))
rh = readHolds.get();
else if (rh.count == 0)
readHolds.set(rh);
rh.count++;
cachedHoldCounter = rh; // cache for release
}
return 1;
}
}
}
其实翻译过来。读锁的加锁逻辑十分清晰，只不过state被分为高16位和低16位以及存储线程中锁的数量的实现比较复杂。
再看写锁的加锁逻辑。其实也十分简单。搞清楚怎么判断读锁或写锁的位运算后，加锁的这部分代码就非常清晰。同样写锁是否需要等待也分公平锁和非公平锁的实现，非公平锁直接就是所有都false.公平锁则需判断头节点下一个节点是不是自己的逻辑。
// 同样走到熟悉的AQS模版方法。看读写锁里Sync的具体实现
public final void acquire(int arg) {
if (!tryAcquire(arg) &&
acquireQueued(addWaiter(Node.EXCLUSIVE), arg))
selfInterrupt();
}
protected final boolean tryAcquire(int acquires) {
Thread current = Thread.currentThread();
int c = getState();
int w = exclusiveCount(c);
// 如果有锁
if (c != 0) {
// (Note: if c != 0 and w == 0 then shared count != 0)
// 如果有写锁，并且排他线程不是当前线程，直接入队列等待
if (w == 0 || current != getExclusiveOwnerThread())
return false;
if (w + exclusiveCount(acquires) > MAX_COUNT)
throw new Error("Maximum lock count exceeded");
// Reentrant acquire
// CAS操作
setState(c + acquires);
return true;
}
// 如果写锁需要等待或者CAS失败，入队列等待。
if (writerShouldBlock() ||
!compareAndSetState(c, c + acquires))
return false;
// 设置排他线程
setExclusiveOwnerThread(current);
return true;
}
关于读写锁源码的阅读，这篇文章写的非常好，同时读写锁的实现也不复杂。文章地址 同时也能更好的理解为嘛有了AQS中的state状态，还要搞个AOS的exclusiveThread属性。每次CAS成功后设置此值。这个其实就是个排他锁的概念，同时也是可重入锁的重要依赖。每次判断state != 0，证明其他线程正在持有锁，此时判断持有锁的线程是不是当前线程，如果是的话就能再次获取锁，实现重入。
